Represents an encoded piece of data that can be placed in an IContainer for a given IStream of data. More...

#include <IPacket.h>

Inheritance diagram for com::avpkit::core::IPacket:

[legend]

Collaboration diagram for com::avpkit::core::IPacket:

[legend]

Public Member Functions
virtual void	reset ()=0
	Clear out any data in this packet, but leaves the buffer available for reuse.

virtual bool	isComplete ()=0
	Is this packet complete. More...

virtual int64_t	getPts ()=0
	Get the Presentation Time Stamp (PTS) for this packet. More...

virtual void	setPts (int64_t aPts)=0
	Set a new Presentation Time Stamp (PTS) for this packet. More...

virtual int64_t	getDts ()=0
	Get the Decompression Time Stamp (DTS) for this packet. More...

virtual void	setDts (int64_t aDts)=0
	Set a new Decompression Time Stamp (DTS) for this packet. More...

virtual int32_t	getSize ()=0
	Get the size in bytes of the payload currently in this packet. More...

virtual int32_t	getMaxSize ()=0
	Get the maximum size (in bytes) of payload this packet can hold. More...

virtual int32_t	getStreamIndex ()=0
	Get the container-specific index for the stream this packet is part of. More...

virtual int32_t	getFlags ()=0
	Get any flags set on this packet, as a 4-byte binary-ORed bit-mask. More...

virtual bool	isKeyPacket ()=0
	Does this packet contain Key data? i.e. More...

virtual int64_t	getDuration ()=0
	Return the duration of this packet, in units of getTimeBase(). More...

virtual int64_t	getPosition ()=0
	Return the position (in bytes) of this packet in the stream. More...

virtual int32_t	allocateNewPayload (int32_t payloadSize)=0
	Discard the current payload and allocate a new payload. More...

virtual void	setKeyPacket (bool keyPacket)=0
	Set if this is a key packet. More...

virtual void	setFlags (int32_t flags)=0
	Set any internal flags. More...

virtual void	setComplete (bool complete, int32_t size)=0
	Set if this packet is complete, and what the total size of the data should be assumed to be. More...

virtual void	setStreamIndex (int32_t streamIndex)=0
	Set the stream index for this packet. More...

virtual void	setDuration (int64_t duration)=0
	Set the duration. More...

virtual void	setPosition (int64_t position)=0
	Set the position. More...

Public Member Functions inherited from com::avpkit::core::IMediaData
virtual int64_t	getTimeStamp ()=0
	Get the time stamp of this object in getTimeBase() units. More...

virtual void	setTimeStamp (int64_t aTimeStamp)=0
	Set the time stamp for this object in getTimeBase() units. More...

virtual IRational *	getTimeBase ()=0
	Get the time base that time stamps of this object are represented in. More...

virtual void	setTimeBase (IRational *aBase)=0
	Set the time base that time stamps of this object are represented in. More...

virtual com::avpkit::ferry::IBuffer *	getData ()=0
	Get any underlying raw data available for this object. More...

virtual bool	isKey ()=0
	Is this object a key object? i.e. More...

virtual void	setData (com::avpkit::ferry::IBuffer *buffer)=0
	Sets the underlying buffer used by this object. More...

Public Member Functions inherited from com::avpkit::ferry::RefCounted
virtual int32_t	acquire ()
	Internal Only. More...

virtual int32_t	release ()
	Internal Only. More...

virtual RefCounted *	copyReference ()
	Create a new Java object that refers to the same native object. More...

virtual int32_t	getCurrentRefCount ()
	Return the current reference count on this object. More...

void	setJavaAllocator (void *allocator)
	This method is public but not part of the standard API. More...

void *	getJavaAllocator ()
	This method is public but not part of the standard API. More...

Static Public Member Functions
static IPacket *	make ()
	Allocate a new packet. More...

static IPacket *	make (com::avpkit::ferry::IBuffer *buffer)
	Allocate a new packet that wraps an existing IBuffer. More...

static IPacket *	make (IPacket *packet, bool copyData)
	Allocate a new packet wrapping the existing contents of a passed in packet. More...

static IPacket *	make (int32_t size)
	Allocate a new packet. More...

Additional Inherited Members
Protected Member Functions inherited from com::avpkit::ferry::RefCounted
virtual void	destroy ()
	This method is called by RefCounted objects when their Ref Count reaches zero and they are about to be destroyed.

Protected Attributes inherited from com::avpkit::ferry::RefCounted
AtomicInteger *	mRefCount
	This is the internal reference count, represented as an AtomicInteger to make sure it is thread safe.

void *	mAllocator
	Not part of public API.

Detailed Description

Represents an encoded piece of data that can be placed in an IContainer for a given IStream of data.

You read this object out of IContainer objects when decoding, and pass to an IStreamCoder object to decode.

You pass this object to a IStreamCoder to encode data, and then pass to an IContainer object to write to a data source.

Lastly, the units of timestamps in an IPacket are determined by the IContainer it came from (or is going to). For example, FLV IPackets are always in milliseconds (1/1000 of a second). You cannot assume these timestamps are in any given timeunit without getting an IStream object and finding out what Time Base that stream operates in.

For convenience, the AVPKit API always uses Microseconds for raw data (IVideoPicture and IAudioSamples objects), and will convert to the right time stamp unit when decoding or encoding data (with an IStreamCoder) from or to an IContainer.

Definition at line 49 of file IPacket.h.

Member Function Documentation

◆ allocateNewPayload()

virtual int32_t com::avpkit::core::IPacket::allocateNewPayload ( int32_t payloadSize )

pure virtual

Discard the current payload and allocate a new payload.

Note that if any people have access to the old payload using getData(), the memory will continue to be available to them until they release their hold of the IBuffer.

When requesting a packet size, the system may allocate a larger payloadSize.

Parameters

payloadSize The (minimum) payloadSize of this packet in bytes.

Returns: >= 0 if successful. < 0 if error.

Implemented in com::avpkit::core::Packet.

Referenced by make().

◆ getDts()

virtual int64_t com::avpkit::core::IPacket::getDts ( )

pure virtual

Get the Decompression Time Stamp (DTS) for this packet.

This is the time at which the payload for this packet should be decompressed, in units of getTimeBase(), relative to the start of stream.

Some media codecs can require packets from the "future" to be decompressed before earliest packets as an additional way to compress data. In general you don't need to worry about this, but if you're curious start reading about the difference between I-Frames, P-Frames and B-Frames (or Bi-Directional Frames). B-Frames can use information from future frames when compressed.

Returns: Get the Decompression Timestamp (i.e. when this was read relative to the start of reading packets).

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

◆ getDuration()

virtual int64_t com::avpkit::core::IPacket::getDuration ( )

pure virtual

Return the duration of this packet, in units of getTimeBase().

Returns: Duration of this packet, in same time-base as the PTS.

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

◆ getFlags()

virtual int32_t com::avpkit::core::IPacket::getFlags ( )

pure virtual

Get any flags set on this packet, as a 4-byte binary-ORed bit-mask.

This is access to raw FFMPEG flags, but it is easier to use the is* methods below.

Returns: Any flags on the packet.

Implemented in com::avpkit::core::Packet.

◆ getMaxSize()

virtual int32_t com::avpkit::core::IPacket::getMaxSize ( )

pure virtual

Get the maximum size (in bytes) of payload this packet can hold.

Returns: Get maximum size (in bytes) of payload this packet can hold.

Implemented in com::avpkit::core::Packet.

◆ getPosition()

virtual int64_t com::avpkit::core::IPacket::getPosition ( )

pure virtual

Return the position (in bytes) of this packet in the stream.

Returns: The position of this packet in the stream, or -1 if unknown.

Implemented in com::avpkit::core::Packet.

◆ getPts()

virtual int64_t com::avpkit::core::IPacket::getPts ( )

pure virtual

Get the Presentation Time Stamp (PTS) for this packet.

This is the time at which the payload for this packet should be presented to the user, in units of getTimeBase(), relative to the start of stream.

Returns: Get the Presentation Timestamp for this packet.

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

◆ getSize()

virtual int32_t com::avpkit::core::IPacket::getSize ( )

pure virtual

Get the size in bytes of the payload currently in this packet.

Returns: Size (in bytes) of payload currently in packet.

Implements com::avpkit::core::IMediaData.

Implemented in com::avpkit::core::Packet.

◆ getStreamIndex()

virtual int32_t com::avpkit::core::IPacket::getStreamIndex ( )

pure virtual

Get the container-specific index for the stream this packet is part of.

Returns: Stream in container that this packet has data for.

Implemented in com::avpkit::core::Packet.

◆ isComplete()

virtual bool com::avpkit::core::IPacket::isComplete ( )

pure virtual

Is this packet complete.

Returns: Is this packet full and therefore has valid information.

Implemented in com::avpkit::core::Packet.

◆ isKeyPacket()

virtual bool com::avpkit::core::IPacket::isKeyPacket ( )

pure virtual

Does this packet contain Key data? i.e.

data that needs no other frames or samples to decode.

Returns: true if key; false otherwise.

Implemented in com::avpkit::core::Packet.

◆ make() [1/4]

IPacket * com::avpkit::core::IPacket::make ( )

static

Allocate a new packet.

Note that any buffers this packet needs will be lazily allocated (i.e. we won't actually grab all the memory until we need it).

Returns: a new packet, or null on error.

Definition at line 37 of file IPacket.cpp.

   {
     Global::init();
     return Packet::make();
   }

References com::avpkit::core::Global::init().

Referenced by make().

◆ make() [2/4]

IPacket * com::avpkit::core::IPacket::make ( com::avpkit::ferry::IBuffer * buffer )

static

Allocate a new packet that wraps an existing IBuffer.

Parameters

buffer The IBuffer to wrap.

Returns: a new packet or null on error.

Definition at line 44 of file IPacket.cpp.

   {
     Global::init();
     if (!buffer)
       throw std::invalid_argument("no buffer");

     return Packet::make(buffer);
   }

References com::avpkit::core::Global::init(), and make().

◆ make() [3/4]

IPacket * com::avpkit::core::IPacket::make ( int32_t size )

static

Allocate a new packet.

Note that any buffers this packet needs will be lazily allocated (i.e. we won't actually grab all the memory until we need it).

Parameters

size	The maximum size, in bytes, of data you want to put in this packet.

Returns: a new packet, or null on error.

Definition at line 61 of file IPacket.cpp.

   {
     Global::init();
     IPacket* retval = make();
     if (retval) {
       if (retval->allocateNewPayload(size) < 0)
         VS_REF_RELEASE(retval);
     }
     return retval;
   }

References allocateNewPayload(), and com::avpkit::core::Global::init().

◆ make() [4/4]

IPacket * com::avpkit::core::IPacket::make	(	IPacket *	packet,
		bool	copyData
	)

static

Allocate a new packet wrapping the existing contents of a passed in packet.

Callers can then modify getPts(), getDts() and other get/set methods without modifying the original packet.

Parameters

packet	Packet to reuse buffer from and to copy settings from.
copyData	if true copy data from packet into our own buffer. If false, share the same data buffer that packet uses

Returns: a new packet or null on error.

Definition at line 54 of file IPacket.cpp.

   {
     Global::init();
     return Packet::make(dynamic_cast<Packet*>(packet), copyData);
   }

References com::avpkit::core::Global::init(), and make().

◆ setComplete()

virtual void com::avpkit::core::IPacket::setComplete	(	bool	complete,
		int32_t	size
	)

pure virtual

Set if this packet is complete, and what the total size of the data should be assumed to be.

Parameters

complete	True for complete, false for not.
size	Size of data in packet.

Implemented in com::avpkit::core::Packet.

◆ setDts()

virtual void com::avpkit::core::IPacket::setDts ( int64_t aDts )

pure virtual

Set a new Decompression Time Stamp (DTS) for this packet.

Parameters

aDts	a new DTS for this packet.

See also: getDts()

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

◆ setDuration()

virtual void com::avpkit::core::IPacket::setDuration ( int64_t duration )

pure virtual

Set the duration.

Parameters

duration new duration

See also: getDuration()

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

◆ setFlags()

virtual void com::avpkit::core::IPacket::setFlags ( int32_t flags )

pure virtual

Set any internal flags.

Parameters

flags Flags to set

Implemented in com::avpkit::core::Packet.

◆ setKeyPacket()

virtual void com::avpkit::core::IPacket::setKeyPacket ( bool keyPacket )

pure virtual

Set if this is a key packet.

Parameters

keyPacket true for yes, false for no.

Implemented in com::avpkit::core::Packet.

◆ setPosition()

virtual void com::avpkit::core::IPacket::setPosition ( int64_t position )

pure virtual

Set the position.

Parameters

position new position

See also: getPosition()

Implemented in com::avpkit::core::Packet.

◆ setPts()

virtual void com::avpkit::core::IPacket::setPts ( int64_t aPts )

pure virtual

Set a new Presentation Time Stamp (PTS) for this packet.

Parameters

aPts	a new PTS for this packet.

See also: getPts()

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

◆ setStreamIndex()

virtual void com::avpkit::core::IPacket::setStreamIndex ( int32_t streamIndex )

pure virtual

Set the stream index for this packet.

Parameters

streamIndex The stream index, as determined from the IContainer this packet will be written to.

Implemented in com::avpkit::core::Packet.

Referenced by com::avpkit::core::Stream::stampOutputPacket().

The documentation for this class was generated from the following files:

csrc/com/avpkit/core/IPacket.h
csrc/com/avpkit/core/IPacket.cpp

Public Member Functions

Static Public Member Functions

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ allocateNewPayload()

◆ getDts()

◆ getDuration()

◆ getFlags()

◆ getMaxSize()

◆ getPosition()

◆ getPts()

◆ getSize()

◆ getStreamIndex()

◆ isComplete()

◆ isKeyPacket()

◆ make() [1/4]

◆ make() [2/4]

◆ make() [3/4]

◆ make() [4/4]

◆ setComplete()

◆ setDts()

◆ setDuration()

◆ setFlags()

◆ setKeyPacket()

◆ setPosition()

◆ setPts()

◆ setStreamIndex()
