Inheritance diagram for com::avpkit::core::Packet:

[legend]

Collaboration diagram for com::avpkit::core::Packet:

[legend]

Public Member Functions
	VS_JNIUTILS_REFCOUNTED_OBJECT (Packet)

virtual int64_t	getTimeStamp ()
	Get the time stamp of this object in getTimeBase() units. More...

virtual void	setTimeStamp (int64_t aTimeStamp)
	Set the time stamp for this object in getTimeBase() units. More...

virtual bool	isKey ()
	Is this object a key object? i.e. More...

virtual IRational *	getTimeBase ()
	Get the time base that time stamps of this object are represented in. More...

virtual void	setTimeBase (IRational *aBase)
	Set the time base that time stamps of this object are represented in. More...

virtual void	reset ()
	Clear out any data in this packet, but leaves the buffer available for reuse.

virtual int64_t	getPts ()
	Get the Presentation Time Stamp (PTS) for this packet. More...

virtual int64_t	getDts ()
	Get the Decompression Time Stamp (DTS) for this packet. More...

virtual int32_t	getSize ()
	Get the size in bytes of the payload currently in this packet. More...

virtual int32_t	getMaxSize ()
	Get the maximum size (in bytes) of payload this packet can hold. More...

virtual int32_t	getStreamIndex ()
	Get the container-specific index for the stream this packet is part of. More...

virtual int32_t	getFlags ()
	Get any flags set on this packet, as a 4-byte binary-ORed bit-mask. More...

virtual bool	isKeyPacket ()
	Does this packet contain Key data? i.e. More...

virtual int64_t	getDuration ()
	Return the duration of this packet, in units of getTimeBase(). More...

virtual int64_t	getPosition ()
	Return the position (in bytes) of this packet in the stream. More...

virtual com::avpkit::ferry::IBuffer *	getData ()
	Get any underlying raw data available for this object. More...

virtual int32_t	allocateNewPayload (int32_t payloadSize)
	Discard the current payload and allocate a new payload. More...

virtual bool	isComplete ()
	Is this packet complete. More...

virtual void	setKeyPacket (bool keyPacket)
	Set if this is a key packet. More...

virtual void	setFlags (int32_t flags)
	Set any internal flags. More...

virtual void	setPts (int64_t pts)
	Set a new Presentation Time Stamp (PTS) for this packet. More...

virtual void	setDts (int64_t dts)
	Set a new Decompression Time Stamp (DTS) for this packet. More...

virtual void	setComplete (bool complete, int32_t size)
	Set if this packet is complete, and what the total size of the data should be assumed to be. More...

virtual void	setStreamIndex (int32_t streamIndex)
	Set the stream index for this packet. More...

virtual void	setDuration (int64_t duration)
	Set the duration. More...

virtual void	setPosition (int64_t position)
	Set the position. More...

virtual void	setData (com::avpkit::ferry::IBuffer *buffer)
	Sets the underlying buffer used by this object. More...

AVPacket *	getAVPacket ()

void	wrapAVPacket (AVPacket *pkt)

void	wrapBuffer (com::avpkit::ferry::IBuffer *buffer)

Public Member Functions inherited from com::avpkit::ferry::RefCounted
virtual int32_t	acquire ()
	Internal Only. More...

virtual int32_t	release ()
	Internal Only. More...

virtual RefCounted *	copyReference ()
	Create a new Java object that refers to the same native object. More...

virtual int32_t	getCurrentRefCount ()
	Return the current reference count on this object. More...

void	setJavaAllocator (void *allocator)
	This method is public but not part of the standard API. More...

void *	getJavaAllocator ()
	This method is public but not part of the standard API. More...

Static Public Member Functions
static Packet *	make (int32_t payloadSize)

static Packet *	make (com::avpkit::ferry::IBuffer *buffer)

static Packet *	make (Packet *packet, bool)

static void	freeAVBuffer (void buf, void closure)

Static Public Member Functions inherited from com::avpkit::core::IPacket
static IPacket *	make ()
	Allocate a new packet. More...

static IPacket *	make (com::avpkit::ferry::IBuffer *buffer)
	Allocate a new packet that wraps an existing IBuffer. More...

static IPacket *	make (IPacket *packet, bool copyData)
	Allocate a new packet wrapping the existing contents of a passed in packet. More...

static IPacket *	make (int32_t size)
	Allocate a new packet. More...

Additional Inherited Members
Protected Member Functions inherited from com::avpkit::ferry::RefCounted
virtual void	destroy ()
	This method is called by RefCounted objects when their Ref Count reaches zero and they are about to be destroyed.

Protected Attributes inherited from com::avpkit::ferry::RefCounted
AtomicInteger *	mRefCount
	This is the internal reference count, represented as an AtomicInteger to make sure it is thread safe.

void *	mAllocator
	Not part of public API.

Detailed Description

Definition at line 30 of file Packet.h.

Member Function Documentation

◆ allocateNewPayload()

int32_t com::avpkit::core::Packet::allocateNewPayload ( int32_t payloadSize )

virtual

Discard the current payload and allocate a new payload.

Note that if any people have access to the old payload using getData(), the memory will continue to be available to them until they release their hold of the IBuffer.

When requesting a packet size, the system may allocate a larger payloadSize.

Parameters

payloadSize The (minimum) payloadSize of this packet in bytes.

Returns: >= 0 if successful. < 0 if error.

Implements com::avpkit::core::IPacket.

Definition at line 309 of file Packet.cpp.

   {
     int32_t retval = -1;
     reset();
     uint8_t* payload = 0;

     // Some FFMPEG encoders will read past the end of a
     // buffer, so you need to allocate extra; yuck.
     if (!mBuffer || mBuffer->getBufferSize() < payloadSize)
     {
       // buffer isn't big enough; we need to make a new one.
       payload = (uint8_t*) av_malloc(payloadSize+AV_INPUT_BUFFER_PADDING_SIZE);
       if (!payload)
         throw std::bad_alloc();

             // we don't use the JVM for packets because Ffmpeg is REAL squirly about that
             mBuffer = Buffer::make(0, payload,
                     payloadSize,
           Packet::freeAVBuffer, 0);
             if (!mBuffer) {
                 av_free(payload);
                 throw std::bad_alloc();
             }
       // and memset the padding area.
       memset(payload + payloadSize,
           0,
           AV_INPUT_BUFFER_PADDING_SIZE);
     } else {
       payload = (uint8_t*)mBuffer->getBytes(0, payloadSize);
     }
     VS_ASSERT(mPacket, "Should already have a packet");
     VS_ASSERT(mBuffer, "Should have allocated a buffer");
     VS_ASSERT(payload, "Should have allocated a payload");
     if (mBuffer && mPacket)
     {
       mPacket->data = payload;

       // And start out at zero.
       mPacket->size = 0;
       this->setComplete(false, 0);

       retval = 0;
     }
     return retval;
   }

References com::avpkit::ferry::Buffer::make().

Referenced by com::avpkit::core::StreamCoder::encodeAudio(), and com::avpkit::core::StreamCoder::encodeVideo().

◆ getData()

com::avpkit::ferry::IBuffer * com::avpkit::core::Packet::getData ( )

virtual

Get any underlying raw data available for this object.

Returns: The raw data, or null if not accessible.

Implements com::avpkit::core::IMediaData.

Definition at line 173 of file Packet.cpp.

   {
     return mBuffer.get();
   }

Referenced by com::avpkit::core::StreamCoder::decodeAudio(), com::avpkit::core::StreamCoder::decodeVideo(), com::avpkit::core::StreamCoder::encodeAudio(), and com::avpkit::core::StreamCoder::encodeVideo().

◆ getDts()

int64_t com::avpkit::core::Packet::getDts ( )

virtual

Get the Decompression Time Stamp (DTS) for this packet.

This is the time at which the payload for this packet should be decompressed, in units of getTimeBase(), relative to the start of stream.

Some media codecs can require packets from the "future" to be decompressed before earliest packets as an additional way to compress data. In general you don't need to worry about this, but if you're curious start reading about the difference between I-Frames, P-Frames and B-Frames (or Bi-Directional Frames). B-Frames can use information from future frames when compressed.

Returns: Get the Decompression Timestamp (i.e. when this was read relative to the start of reading packets).

Implements com::avpkit::core::IPacket.

Definition at line 75 of file Packet.cpp.

   {
     return (mPacket ? mPacket->dts : (int64_t)-1);
   }

Referenced by getTimeStamp(), and com::avpkit::core::Container::readNextPacket().

◆ getDuration()

int64_t com::avpkit::core::Packet::getDuration ( )

virtual

Return the duration of this packet, in units of getTimeBase().

Returns: Duration of this packet, in same time-base as the PTS.

Implements com::avpkit::core::IPacket.

Definition at line 149 of file Packet.cpp.

   {
     return (mPacket ? mPacket->duration: (int64_t)-1);
   }

Referenced by com::avpkit::core::Container::readNextPacket().

◆ getFlags()

int32_t com::avpkit::core::Packet::getFlags ( )

virtual

Get any flags set on this packet, as a 4-byte binary-ORed bit-mask.

This is access to raw FFMPEG flags, but it is easier to use the is* methods below.

Returns: Any flags on the packet.

Implements com::avpkit::core::IPacket.

Definition at line 102 of file Packet.cpp.

   {
     return (mPacket ? mPacket->flags: (int32_t)-1);
   }

Referenced by com::avpkit::core::Container::readNextPacket().

◆ getMaxSize()

int32_t com::avpkit::core::Packet::getMaxSize ( )

virtual

Get the maximum size (in bytes) of payload this packet can hold.

Returns: Get maximum size (in bytes) of payload this packet can hold.

Implements com::avpkit::core::IPacket.

Definition at line 92 of file Packet.cpp.

   {
     return (mBuffer ? mBuffer->getBufferSize() : -1);
   }

◆ getPosition()

int64_t com::avpkit::core::Packet::getPosition ( )

virtual

Return the position (in bytes) of this packet in the stream.

Returns: The position of this packet in the stream, or -1 if unknown.

Implements com::avpkit::core::IPacket.

Definition at line 161 of file Packet.cpp.

   {
     return (mPacket ? mPacket->pos: (int64_t)-1);
   }

Referenced by com::avpkit::core::Container::readNextPacket().

◆ getPts()

int64_t com::avpkit::core::Packet::getPts ( )

virtual

Get the Presentation Time Stamp (PTS) for this packet.

This is the time at which the payload for this packet should be presented to the user, in units of getTimeBase(), relative to the start of stream.

Returns: Get the Presentation Timestamp for this packet.

Implements com::avpkit::core::IPacket.

Definition at line 63 of file Packet.cpp.

   {
     return (mPacket ? mPacket->pts : (int64_t)-1);
   }

Referenced by com::avpkit::core::StreamCoder::decodeAudio(), and com::avpkit::core::Container::readNextPacket().

◆ getSize()

int32_t com::avpkit::core::Packet::getSize ( )

virtual

Get the size in bytes of the payload currently in this packet.

Returns: Size (in bytes) of payload currently in packet.

Implements com::avpkit::core::IPacket.

Definition at line 87 of file Packet.cpp.

   {
     return (mPacket ? mPacket->size: (int32_t)-1);
   }

Referenced by com::avpkit::core::StreamCoder::decodeAudio(), com::avpkit::core::StreamCoder::decodeVideo(), com::avpkit::core::StreamCoder::encodeAudio(), and com::avpkit::core::Container::readNextPacket().

◆ getStreamIndex()

int32_t com::avpkit::core::Packet::getStreamIndex ( )

virtual

Get the container-specific index for the stream this packet is part of.

Returns: Stream in container that this packet has data for.

Implements com::avpkit::core::IPacket.

Definition at line 97 of file Packet.cpp.

   {
     return (mPacket ? mPacket->stream_index: (int32_t)-1);
   }

Referenced by com::avpkit::core::Container::readNextPacket(), and com::avpkit::core::Container::writePacket().

◆ getTimeBase()

virtual IRational* com::avpkit::core::Packet::getTimeBase ( )

inlinevirtual

Get the time base that time stamps of this object are represented in.

Caller must release the returned value.

Returns: the time base.

Implements com::avpkit::core::IMediaData.

Definition at line 49 of file Packet.h.

49 { return mTimeBase.get(); }

◆ getTimeStamp()

virtual int64_t com::avpkit::core::Packet::getTimeStamp ( )

inlinevirtual

Get the time stamp of this object in getTimeBase() units.

Returns: the time stamp

Implements com::avpkit::core::IMediaData.

Definition at line 46 of file Packet.h.

46 { return getDts(); }

com::avpkit::core::Packet::getDts

virtual int64_t getDts()

Get the Decompression Time Stamp (DTS) for this packet.

Definition: Packet.cpp:75

References getDts().

◆ isComplete()

bool com::avpkit::core::Packet::isComplete ( )

virtual

Is this packet complete.

Returns: Is this packet full and therefore has valid information.

Implements com::avpkit::core::IPacket.

Definition at line 384 of file Packet.cpp.

   {
     return mIsComplete && mPacket->data;
   }

Referenced by com::avpkit::core::Container::writePacket().

◆ isKey()

virtual bool com::avpkit::core::Packet::isKey ( )

inlinevirtual

Is this object a key object? i.e.

it can be interpreted without needing any other media objects

Returns: true if it's a key, false if not

Implements com::avpkit::core::IMediaData.

Definition at line 48 of file Packet.h.

48 { return isKeyPacket(); }

com::avpkit::core::Packet::isKeyPacket

virtual bool isKeyPacket()

Does this packet contain Key data? i.e.

Definition: Packet.cpp:107

References isKeyPacket().

◆ isKeyPacket()

bool com::avpkit::core::Packet::isKeyPacket ( )

virtual

Does this packet contain Key data? i.e.

data that needs no other frames or samples to decode.

Returns: true if key; false otherwise.

Implements com::avpkit::core::IPacket.

Definition at line 107 of file Packet.cpp.

   {
     return (mPacket ? mPacket->flags & AV_PKT_FLAG_KEY : false);
   }

Referenced by isKey().

◆ setComplete()

void com::avpkit::core::Packet::setComplete	(	bool	complete,
		int32_t	size
	)

virtual

Set if this packet is complete, and what the total size of the data should be assumed to be.

Parameters

complete	True for complete, false for not.
size	Size of data in packet.

Implements com::avpkit::core::IPacket.

Definition at line 132 of file Packet.cpp.

   {
     mIsComplete = complete;
     if (mIsComplete)
     {
       if (mPacket)
         mPacket->size = size;
     }
   }

◆ setData()

void com::avpkit::core::Packet::setData ( com::avpkit::ferry::IBuffer * buffer )

virtual

Sets the underlying buffer used by this object.

This is an advanced method and is not recommended for use by those who don't fully understand how IBuffers work. Implementations of IMediaData may behave in undefined ways if the buffer you pass in is not big enough for what you ask them to do (e.g. they may discard your buffer and allocate a larger one if they need more space). It is up to the caller to ensure the buffer passed in is large enough, and is not simultaneously in use by another part of the system.

Parameters

buffer The buffer to set. If null, this method is ignored.

Implements com::avpkit::core::IMediaData.

Definition at line 356 of file Packet.cpp.

   {
     wrapBuffer(buffer);
   }

◆ setDts()

void com::avpkit::core::Packet::setDts ( int64_t aDts )

virtual

Set a new Decompression Time Stamp (DTS) for this packet.

Parameters

aDts	a new DTS for this packet.

See also: getDts()

Implements com::avpkit::core::IPacket.

Definition at line 81 of file Packet.cpp.

   {
     if (mPacket) mPacket->dts = aDts;
   }

Referenced by setTimeStamp().

◆ setDuration()

void com::avpkit::core::Packet::setDuration ( int64_t duration )

virtual

Set the duration.

Parameters

duration new duration

See also: getDuration()

Implements com::avpkit::core::IPacket.

Definition at line 155 of file Packet.cpp.

   {
     if (mPacket) mPacket->duration = duration;
   }

◆ setFlags()

void com::avpkit::core::Packet::setFlags ( int32_t flags )

virtual

Set any internal flags.

Parameters

flags Flags to set

Implements com::avpkit::core::IPacket.

Definition at line 125 of file Packet.cpp.

   {
     if (mPacket)
       mPacket->flags = flags;
   }

◆ setKeyPacket()

void com::avpkit::core::Packet::setKeyPacket ( bool keyPacket )

virtual

Set if this is a key packet.

Parameters

keyPacket true for yes, false for no.

Implements com::avpkit::core::IPacket.

Definition at line 113 of file Packet.cpp.

   {
     if (mPacket)
     {
       if (bKeyPacket)
         mPacket->flags |= AV_PKT_FLAG_KEY;
       else
         mPacket->flags = 0;
     }
   }

◆ setPosition()

void com::avpkit::core::Packet::setPosition ( int64_t position )

virtual

Set the position.

Parameters

position new position

See also: getPosition()

Implements com::avpkit::core::IPacket.

Definition at line 167 of file Packet.cpp.

   {
     if (mPacket) mPacket->pos = position;
   }

◆ setPts()

void com::avpkit::core::Packet::setPts ( int64_t aPts )

virtual

Set a new Presentation Time Stamp (PTS) for this packet.

Parameters

aPts	a new PTS for this packet.

See also: getPts()

Implements com::avpkit::core::IPacket.

Definition at line 69 of file Packet.cpp.

   {
     if (mPacket) mPacket->pts = aPts;
   }

◆ setStreamIndex()

void com::avpkit::core::Packet::setStreamIndex ( int32_t streamIndex )

virtual

Set the stream index for this packet.

Parameters

streamIndex The stream index, as determined from the IContainer this packet will be written to.

Implements com::avpkit::core::IPacket.

Definition at line 143 of file Packet.cpp.

   {
     if (mPacket)
       mPacket->stream_index = streamIndex;
   }

◆ setTimeBase()

virtual void com::avpkit::core::Packet::setTimeBase ( IRational * aBase )

inlinevirtual

Set the time base that time stamps of this object are represented in.

Parameters

aBase the new time base. If null an exception is thrown.

Implements com::avpkit::core::IMediaData.

Definition at line 50 of file Packet.h.

50 { mTimeBase.reset(aBase, true); }

Referenced by com::avpkit::core::Container::readNextPacket().

◆ setTimeStamp()

virtual void com::avpkit::core::Packet::setTimeStamp ( int64_t aTimeStamp )

inlinevirtual

Set the time stamp for this object in getTimeBase() units.

Parameters

aTimeStamp The time stamp

Implements com::avpkit::core::IMediaData.

Definition at line 47 of file Packet.h.

47 { setDts(aTimeStamp); }

com::avpkit::core::Packet::setDts

virtual void setDts(int64_t dts)

Set a new Decompression Time Stamp (DTS) for this packet.

Definition: Packet.cpp:81

References setDts().

The documentation for this class was generated from the following files:

csrc/com/avpkit/core/Packet.h
csrc/com/avpkit/core/Packet.cpp

Public Member Functions

Static Public Member Functions

Additional Inherited Members

Detailed Description

Member Function Documentation

◆ allocateNewPayload()

◆ getData()

◆ getDts()

◆ getDuration()

◆ getFlags()

◆ getMaxSize()

◆ getPosition()

◆ getPts()

◆ getSize()

◆ getStreamIndex()

◆ getTimeBase()

◆ getTimeStamp()

◆ isComplete()

◆ isKey()

◆ isKeyPacket()

◆ setComplete()

◆ setData()

◆ setDts()

◆ setDuration()

◆ setFlags()

◆ setKeyPacket()

◆ setPosition()

◆ setPts()

◆ setStreamIndex()

◆ setTimeBase()

◆ setTimeStamp()
